Lithium-ion Battery Separator-grade PVDF
PHYSICAL PROPERTIE
| Item | Unit | Index | Test Method / Standards |
| Appearance | / | White Powder | Visual inspection |
| Particle Size D50 | μm | 10±5 | GB/T 19077.1 |
| Relative Density | g/cm³ | 1.75-1.77 | GB/T 1033.1 |
| Melting Point | ℃ | 155±5 | GB/T 19466.3 |
| Moisture Content | % | ≤0.1 | GB/T 6284 |
| Thermal Decomposition Temperature | ℃ | ≥380 | GB/T 33047 |
| Melt Flow Index | g/10min | ≤4.0 | GB/T 3682，230℃/12.5kg |
| Rotational Viscosity | mpa.s | 500~4000 | 25℃，0.1g/g NMP |
Product Description
This product is a powdered polyvinylidene fluoride copolymer, mainly used for coating lithium battery separators. It can effectively improve the wettability and electrolyte retention of PE and PP separators, which is more conducive to the battery hot pressing process and can increase the electrochemical stability of the separator and the safety of the battery.
Application
It is mainly used for coating lithium battery separators, and can be used for both oil-based and water-based coatings.
Packaging
- Packed in polyethylene plastic bags, and then sealed in outer packaging bags, each bag contains a net weight of 25 kg.
- Packed in plastic bags, then into paper drums, each drum containing 20kg net weight.
Transportation & Storage
Transportation: Transport as non-dangerous goods. Avoid heat, moisture, or severe vibration during transportation.
Storage:It should be stored in a clean and dry environment at 5~30℃ to prevent impurities such as dust and water vapor from mixing in.
Attention
Avoid processing or using at temperatures above 350℃ to prevent decomposition and the generation of toxic gases.
